- Integrated aluminum oil tank, capacity: 13L for up to 35 hours running time
- Integrated air injection system for continuous vacuum operation
- High capacity fan forced air cooling
- High capacity metered oil injection pump for precise oil delivery under various operating conditions
- Available with different mounting and drive options
- Quietest operation in its class, only 85 dB at 10ft
The RCF1400 is Fruitland’s newest and most powerful rotary vane pump. Offering simplicity, superiority, and serviceability of fan cooling and boasts an integrated air injection system for continuous duty applications. With an improved integrated oil reservoir and air filter, the RCF1400 is simply a powerhouse which can tackle any pumping job in any environment – any time.
Maximum Air flow: 910 CFM (ft³/min)
Maximum Vacuum: 27.5 in-Hg
Power Required @ 27” in-Hg: 42 HP to 64 HP
Max Pressure: 20 PSI
Porting Size: Ø4.0”
Maximum Input Speed: 1400 RPM
Net Pump Weight: 1262 lbs
1400LUF
- Left (Counter Clockwise)
- Upper (Top Valve)
- Integrated Filter
1400LSF
- Left (Counter Clockwise)
- Side Valve
- Integrated Filter
1400LUFH
- Left (Counter Clockwise)
- Upper (Top Valve)
- Integrated Filter
- Hydraulic Drive Adapter
1400LSFH
- Left (Counter Clockwise)
- Side Valve
- Integrated Filter
- Hydraulic Drive Adapter
1400RUF
- Right (Clockwise)
- Upper (Top Valve)
- Integrated Filter
1400RSF
- Right (Clockwise)
- Side Valve
- Integrated Filter
1400RUFH
- Right (Clockwise)
- Upper (Top Valve)
- Integrated Filter
- Hydraulic Drive Adapter
1400RSFH
- Right (Clockwise)
- Side Valve
- Integrated Filter
- Hydraulic Drive Adapter
